Note: ssh with GUI via: ssh -Y usr@host, if using XLaunch (VcXsrv), set $env:DISPLAY="localhost:0" in PS prior to SSH

Resources:

• isaac_ros_object_detection documentation
• Jetson AI Lab Tutorial - Ultralytics YOLOv8

Pre-setup in host environment

Go to the ISAAC ROS ($ISAAC_ROS_WS) workspace

cd ${ISAAC_ROS_WS}/src/isaac_ros_common

Installing libraries (outside container)

sudo apt-get install -y curl jq tar

Bash script to download assets from NGC

NGC_ORG="nvidia"
NGC_TEAM="isaac"
PACKAGE_NAME="isaac_ros_yolov8"
NGC_RESOURCE="isaac_ros_yolov8_assets"
NGC_FILENAME="quickstart.tar.gz"
MAJOR_VERSION=3
MINOR_VERSION=2
VERSION_REQ_URL="https://catalog.ngc.nvidia.com/api/resources/versions?orgName=$NGC_ORG&teamName=$NGC_TEAM&name=$NGC_RESOURCE&isPublic=true&pageNumber=0&pageSize=100&sortOrder=CREATED_DATE_DESC"
AVAILABLE_VERSIONS=$(curl -s \
    -H "Accept: application/json" "$VERSION_REQ_URL")
LATEST_VERSION_ID=$(echo $AVAILABLE_VERSIONS | jq -r "
    .recipeVersions[]
    | .versionId as \$v
    | \$v | select(test(\"^\\\\d+\\\\.\\\\d+\\\\.\\\\d+$\"))
    | split(\".\") | {major: .[0]|tonumber, minor: .[1]|tonumber, patch: .[2]|tonumber}
    | select(.major == $MAJOR_VERSION and .minor <= $MINOR_VERSION)
    | \$v
    " | sort -V | tail -n 1
)
if [ -z "$LATEST_VERSION_ID" ]; then
    echo "No corresponding version found for Isaac ROS $MAJOR_VERSION.$MINOR_VERSION"
    echo "Found versions:"
    echo $AVAILABLE_VERSIONS | jq -r '.recipeVersions[].versionId'
else
    mkdir -p ${ISAAC_ROS_WS}/isaac_ros_assets && \
    FILE_REQ_URL="https://api.ngc.nvidia.com/v2/resources/$NGC_ORG/$NGC_TEAM/$NGC_RESOURCE/\
versions/$LATEST_VERSION_ID/files/$NGC_FILENAME" && \
    curl -LO --request GET "${FILE_REQ_URL}" && \
    tar -xf ${NGC_FILENAME} -C ${ISAAC_ROS_WS}/isaac_ros_assets && \
    rm ${NGC_FILENAME}
fi

Fetch YOLO model of choice (example with yolov8s, see model comparison here):

cd Downloads && \
   wget https://github.com/ultralytics/assets/releases/download/v0.0.0/yolov8s.pt

Install ultralytics and onnx pip packages to export

pip3 install ultralytics
pip3 install onnx

Invoke the python interpreter

python3

Export the YOLO model as onnx

from ultralytics import YOLO
model = YOLO('yolov8s.pt')
model.export(format='onnx')
quit()

Copy the onnx model inside the workspace

mkdir -p ${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8
cp yolov8s.onnx ${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8

ZED-camera specific: clone the zed-ros2-wrapper

cd ${ISAAC_ROS_WS}/src && \
git clone --recurse-submodules https://github.com/stereolabs/zed-ros2-wrapper -b humble-v4.2.5

In the docker workspace/container

To start, launch the container

cd ${ISAAC_ROS_WS}/src/isaac_ros_common && \
./scripts/run_dev.sh

If it fails to launch with docker: Error response from daemon: failed to create task for container: failed to create shim task: OCI runtime create failed: could not apply required modification to OCI specification: error modifying OCI spec: failed to inject CDI devices: failed to inject devices: failed to stat CDI host device "/dev/fb0": no such file or directory: unknown, try the following:

sudo nvidia-ctk cdi generate --mode=csv --output=/etc/cdi/nvidia.yaml

Option 1. Setup script

sudo chmod +x ${ISAAC_ROS_WS}/src/isaac_ros_common/docker/scripts/install-zed-aarch64.sh && \
${ISAAC_ROS_WS}/src/isaac_ros_common/docker/scripts/install-zed-aarch64.sh

cd ${ISAAC_ROS_WS} && \
sudo apt-get update && sudo apt update && rosdep update && \
sudo apt-get install -y ros-humble-isaac-ros-yolov8 ros-humble-isaac-ros-dnn-image-encoder ros-humble-isaac-ros-tensor-rt
sudo apt-get install -y ros-humble-isaac-ros-examples ros-humble-isaac-ros-stereo-image-proc ros-humble-isaac-ros-zed

rosdep install --from-paths src --ignore-src -r -y
colcon build --symlink-install --cmake-args=-DCMAKE_BUILD_TYPE=Release --parallel-workers $(nproc)
echo source $(pwd)/install/local_setup.bash >> ~/.bashrc
source ~/.bashrc

Option 2. Setup with explanations

2.1 ZED setup

Nvidia docs

Install the Zed SDK

sudo chmod +x ${ISAAC_ROS_WS}/src/isaac_ros_common/docker/scripts/install-zed-aarch64.sh && \
${ISAAC_ROS_WS}/src/isaac_ros_common/docker/scripts/install-zed-aarch64.sh

Install ZED wrapper dependencies

cd ${ISAAC_ROS_WS} && \
apt get update && rosdep update && \
rosdep install --from-paths src/zed-ros2-wrapper --ignore-src -r -y && \
colcon build --symlink-install --packages-up-to zed_wrapper

Try launching the ZED Explorer GUI

/usr/local/zed/tools/ZED_Explorer

2.2 Yolov8 setup

General dependencies

sudo apt-get update && \
sudo apt-get install -y ros-humble-isaac-ros-yolov8 ros-humble-isaac-ros-dnn-image-encoder ros-humble-isaac-ros-tensor-rt

ZED-camera example specific dependencies

sudo apt-get install -y ros-humble-isaac-ros-examples ros-humble-isaac-ros-stereo-image-proc ros-humble-isaac-ros-zed

Install packages, build the workspace & source it to .bashrc (for other terminals in the container)

rosdep install --from-paths src --ignore-src -r -y # install dependencies
colcon build --symlink-install --cmake-args=-DCMAKE_BUILD_TYPE=Release --parallel-workers $(nproc) # build the workspace
echo source $(pwd)/install/local_setup.bash >> ~/.bashrc
source ~/.bashrc

Running YOLOv8

Launch the isaac_ros_examples node:

ros2 launch isaac_ros_examples isaac_ros_examples.launch.py \
launch_fragments:=zed_mono_rect,yolov8 \
model_file_path:=${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8/yolov8s.onnx engine_file_path:=${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8/yolov8s.plan \
interface_specs_file:=${ISAAC_ROS_WS}/isaac_ros_assets/isaac_ros_yolov8/zed2_quickstart_interface_specs.json

Enter the docker container in a second terminal and run visualization

cd ${ISAAC_ROS_WS}/src/isaac_ros_common && \
./scripts/run_dev.sh

ros2 run isaac_ros_yolov8 isaac_ros_yolov8_visualizer.py

Enter the docker container in a third terminal and run GUI

cd ${ISAAC_ROS_WS}/src/isaac_ros_common && \
./scripts/run_dev.sh

ros2 run rqt_image_view rqt_image_view /yolov8_processed_image

The above is effectively an example launch script which also launches some nodes of the zed wrapper under a different namespace. Below shows the launch format of just the yolo including some arguments, but further requires mapping to input topics.

ros2 launch isaac_ros_yolov8 isaac_ros_yolov8_visualize.launch.py \
model_file_path:=${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8/yolov8s.onnx \
engine_file_path:=${ISAAC_ROS_WS}/isaac_ros_assets/models/yolov8/yolov8s.plan \
input_binding_names:=['images'] \
output_binding_names:=['output0'] \
network_image_width:=640 \
network_image_height:=640 \
force_engine_update:=False \
image_mean:=[0.0,0.0,0.0] \
image_stddev:=[1.0,1.0,1.0] \
input_image_width:=640 \
input_image_height:=640 \
confidence_threshold:=0.25 \
nms_threshold:=0.45
